(型號) Model |
(軸承類型) Bearing Type |
(電壓) Rated Voltage |
(電壓范圍) Operation Voltage |
(電流) Current |
(轉數) Speed |
(風量) Air Flow |
(風壓) Static Pressure |
(噪音) Noise Level |
(重量) Weight |
VDC | VDC | A | RPM | CFM | mmH20 | dBA | g | ||
JDH7515S | Sleeve | 5 | 4.5~5.5 | 0.35 | 3500 | 8.68 | 10.56 | 32.6 | 46 |
JDM7515S | 0.27 | 3000 | 7.44 | 9.05 | 27.9 | ||||
JDL7515S | 0.18 | 2500 | 6.20 | 7.54 | 23.3 | ||||
JDH7515B | Ball | 0.35 | 3500 | 8.68 | 10.56 | 32.6 | |||
JDM7515B | 0.27 | 3000 | 7.44 | 9.05 | 27.9 | ||||
JDL7515B | 0.18 | 2500 | 6.20 | 7.54 | 23.3 | ||||
JDH7515S | Sleeve | 12 | 10.8~13.2 | 0.20 | 3500 | 8.68 | 10.56 | 32.6 | |
JDM7515S | 0.15 | 3000 | 7.44 | 9.05 | 27.9 | ||||
JDL7515S | 0.10 | 2500 | 6.20 | 7.54 | 23.3 | ||||
JDH7515B | Ball | 0.20 | 3500 | 8.68 | 10.56 | 32.6 | |||
JDM7515B | 0.15 | 3000 | 7.44 | 9.05 | 27.9 | ||||
JDL7515B | 0.10 | 2500 | 6.20 | 7.54 | 23.3 |
